一、燃?xì)庀到y(tǒng)問題

1、 Gas system issues

（一）燃?xì)鈮毫Σ▌?dòng)

（1） Gas pressure fluctuation

燃?xì)鈮毫Σ▌?dòng)是影響瓦斯發電機組穩定運行的常見問題。經分析，其產生原因主要有以下幾點：

Gas pressure fluctuations are a common problem that affects the stable operation of gas generators. After analysis, the main reasons for its occurrence are as follows:

氣源壓力不穩：當氣源壓力變化幅度超過設定值的 10% 時，會直接導致進入機組的燃?xì)鈮毫Σ▌?dòng)，進而影響燃燒穩定性。

Unstable gas source pressure: When the change in gas source pressure exceeds 10% of the set value, it will directly cause fluctuations in the gas pressure entering the unit, thereby affecting combustion stability.

調壓閥故障：若調壓閥響應時間超過 2 秒，無法及時對壓力變化做出調節，同樣會造成燃?xì)鈮毫Σ环€(wěn)定。

Pressure regulating valve malfunction: If the response time of the pressure regulating valve exceeds 2 seconds, it cannot adjust the pressure changes in a timely manner, which can also cause unstable gas pressure.

濾芯堵塞：當濾芯前后壓差大于 5kPa 時，氣體流通受阻，這也會引起燃?xì)鈮毫Σ▌?dòng)。

Filter blockage: When the pressure difference between the front and rear of the filter is greater than 5kPa, gas flow is blocked, which can also cause fluctuations in gas pressure.

針對燃?xì)鈮毫Σ▌?dòng)問題，可采取以下解決方案：

The following solutions can be taken to address the issue of gas pressure fluctuations:

建立氣源壓力監測與反饋機制，實時跟蹤氣源壓力變化，必要時與供氣方協調穩定氣源壓力；定期檢修調壓閥，確保其響應靈敏，若出現故障及時更換或維修；按規定周期清理或更換濾芯，維持氣體順暢流通，保證燃?xì)鈮毫Ψ€(wěn)定。

Establish a monitoring and feedback mechanism for gas source pressure, track changes in gas source pressure in real time, and coordinate with the gas supply party to stabilize gas source pressure when necessary; Regularly inspect the pressure regulating valve to ensure its responsiveness, and replace or repair it promptly in case of any malfunction; Clean or replace the filter element according to the prescribed cycle, maintain smooth gas flow, and ensure stable gas pressure.

（二）甲烷濃度變化

（2） Changes in methane concentration

甲烷作為瓦斯氣的主要可燃成分，其濃度變化會顯著影響機組運行。為應對甲烷濃度變化，可采取以下措施：

Methane, as the main combustible component of gas, can significantly affect the operation of the unit when its concentration changes. To cope with changes in methane concentration, the following measures can be taken:

安裝在線色譜儀：實現對甲烷濃度的快速檢測，檢測周期小于 30 秒，以便及時掌握濃度動態。

Install online chromatograph: achieve rapid detection of methane concentration, with a detection cycle of less than 30 seconds, in order to timely grasp the concentration dynamics.

調整空燃比：將空燃比（λ）控制在 1.8 - 2.2 的合理區間，確保燃?xì)獬浞秩紵岣邫C(jī)組效率。

Adjust air-fuel ratio: Control the air-fuel ratio (λ) within a reasonable range of 1.8-2.2 to ensure full combustion of gas and improve unit efficiency.

設置濃度聯鎖：當甲烷濃度低于 30% 時，自動降低機組負荷，避免因燃?xì)鉄嶂挡蛔銓?dǎo)致機組運行異常 。

Set concentration interlock: When the methane concentration is below 30%, the unit load will be automatically reduced to avoid abnormal operation of the unit due to insufficient gas calorific value.

二、發動機故障

2、 Engine malfunction

（一）爆震現象

（1） Detonation phenomenon

爆震現象會對發動機造成嚴重?fù)p害。當出現高頻金屬聲時，通常是由于點火提前角過大導致，此時需要將點火提前角調整至 25 - 35°CA，使燃燒過程更平穩；若出現功率突降的情況，往往是因?yàn)槿細鉄嶂低蛔儯刹捎脽嶂笛a(bǔ)償控制策略，根據燃?xì)鉄嶂底兓詣?dòng)調整燃燒參數；而排溫異常則多是由于混合不均勻引起，需要對混合器結構進行優化，促進燃?xì)馀c空氣充分混合。

The phenomenon of detonation can cause serious damage to the engine. When high-frequency metallic sound occurs, it is usually caused by a too large ignition advance angle. At this time, the ignition advance angle needs to be adjusted to 25-35 ° CA to make the combustion process smoother; If there is a sudden drop in power, it is often due to a sudden change in gas calorific value. A calorific value compensation control strategy can be used to automatically adjust combustion parameters based on the change in gas calorific value; Abnormal exhaust temperature is often caused by uneven mixing, and it is necessary to optimize the structure of the mixer to promote sufficient mixing of gas and air.

（二）氣缸溫度異常

（2） Abnormal cylinder temperature

為有效控制氣缸溫度異常，可采取以下控制策略：

To effectively control abnormal cylinder temperature, the following control strategies can be adopted:

冷卻水溫度監測：將冷卻水溫度控制在 85 - 95℃的最佳范圍，通過冷卻系統調節維持合適的溫度，保障發動機正常散熱。

Cooling water temperature monitoring: Control the cooling water temperature within the optimal range of 85-95 ℃, adjust and maintain the appropriate temperature through the cooling system, and ensure normal engine heat dissipation.

紅外熱像儀檢測：利用紅外熱像儀實時監測氣缸溫度，當各部位溫差超過 15℃時及時報警，以便排查溫度異常原因。

Infrared thermal imager detection: Real time monitoring of cylinder temperature using an infrared thermal imager, and timely alarm when the temperature difference between different parts exceeds 15 ℃, in order to investigate the cause of temperature abnormalities.

缸套水流量調節：確保各缸缸套水流量單缸偏差小于 5%，保證各氣缸冷卻均勻，防止局部過熱 。

Cylinder liner water flow regulation: Ensure that the cylinder liner water flow of each cylinder has a single cylinder deviation of less than 5%, ensure uniform cooling of each cylinder, and prevent local overheating.

三、發電系統故障

3、 Power generation system malfunction

（一）電壓波動

（1） Voltage fluctuation

電壓波動會影響發電質量和設備穩定性，可通過以下技術措施解決：

Voltage fluctuations can affect the quality of power generation and equipment stability, and can be resolved through the following technical measures:

AVR 響應優化：將自動電壓調節器（AVR）的響應時間縮短至 20ms 以內，使其能快速對電壓變化做出調節。

AVR response optimization: Shorten the response time of the automatic voltage regulator (AVR) to within 20ms, enabling it to quickly adjust to voltage changes.

增加穩壓電容：安裝容量不小于 1000μF 的穩壓電容，增強系統穩壓能力，減少電壓波動。

Increase voltage regulator capacitor: Install a voltage regulator capacitor with a capacity of not less than 1000 μ F to enhance the system's voltage regulation capability and reduce voltage fluctuations.

檢查轉子繞組：定期檢測轉子繞組，確保其阻抗偏差小于 5%，保證發電系統正常運行。

Check the rotor winding: Regularly inspect the rotor winding to ensure that its impedance deviation is less than 5%, ensuring the normal operation of the power generation system.

（二）并網不同步

（2） Asynchronous grid connection

實現瓦斯發電機組順利并網，需滿足以下同步條件：機組輸出電壓與電網電壓差需控制在 ±5% 以內；機組發電頻率與電網頻率差應小于 ±0.2Hz；機組與電網的相位差需保持在 ±10° 以內 。

To achieve smooth grid connection of gas generator units, the following synchronization conditions must be met: the difference between the output voltage of the unit and the grid voltage must be controlled within ± 5%; The difference between the generator frequency and the grid frequency should be less than ± 0.2Hz; The phase difference between the unit and the power grid should be kept within ± 10 °.

并網前的校準步驟如下：仔細檢查電壓互感器（PT）和電流互感器（CT）的變比，確保測量準確；合理調整調速器的 PID 參數，優化機組的頻率和功率調節性能；對同步繼電器進行驗證，保證其能準確判斷并網條件，實現可靠并網。

The calibration steps before grid connection are as follows: carefully check the transformation ratio of the voltage transformer (PT) and current transformer (CT) to ensure accurate measurement; Reasonably adjust the PID parameters of the governor to optimize the frequency and power regulation performance of the unit; Verify the synchronous relay to ensure it can accurately determine the grid connection conditions and achieve reliable grid connection.
